Technical Parameters:
Genset Model: LY1200GL/M/H-T
Electrical Power: 1080 kW
Fuel Consumption: 2634 kW
Electrical Efficiency: 41.0%
Thermal Efficiency: 46.5%
Total Efficiency: 87.5%
Frequency: 50Hz / 60Hz
Dimensions:L: 5700 mm x W: 1700 mm x H: 2650 mm 1}
Note: Factors such as gas quality, air pressure, calorific value, operating environment, and personnel operation level will affect the final output of the unit.
1}For the transportation size of genset, the components set separately must be considered separately
2}NOx emission: NOx ≤ 500 mg/Nm³, NOx/Nm³ (Content of dry exhaust gas in 5% O₂)
3}Refers to ISO8525-1, 50Hz Generator U=10kV, Cosphi=1.0, the minimum methane number of natural gas is MN70
4}Refers to ISO3046-1, 50Hz Generator U=10kV, Cosphi=1.0, the minimum methane number of natural gas is MN70
